NJP-2500C
GRAND PACKING
8422303090
Product Description
The machine is an intermittent motion and hole plate type filling fully automatic capsule filling equipment. It adopt optimization design combined the characteristics of Chinese medicine and the requirement of GMP, it has the characteristics of compact mechanism, small volume, lower noise, precision filling dosage, multi-function, running stably etc. It can finish the following motion at same time: capsule feeding, capsule separating, powder filling, capsule rejecting, capsule locking, finished capsule discharge and module cleaning etc.
This machine is designed for meet the volume-produce on the basis of model NJP-1200 automatic capsule filling machine. it increase the lifting mechanism that easy to clean. It saves the cost and manpower for the enterprise that need volume-produce.
Main Features
1.It has been improved the inner design turret, and imports beeline bearings for each machine from Japan directly, so that it can be sure to get a longer usage-life and precision of machine.
2.The working station cam runs under the good lubricating condition, and maintains the inner lubrication of cam slot to a full extent, increasing the pressure pulverization oil pump, thus extends the operation life of the spare parts.
3.It is controlled by the computer, has a step less timing with the frequency-conversion, the numeral showing makes an easy operation and clear appearance.
4.The multi-bore dosing brings a precision dosage (it is controlled around ±3.5%); The capsule qualified rate is higher than 99%.It can be filled with the Chinese traditional medicine and the Western medicine.
5.It has a protector equipment for the operator and the machine. It has automatic pause equipment when it is lack of the material. It has a steady and safe working, therefore it is the best choice for the hard capsule factories.
6.Additional function of blowing and suction of mould, which ensures the clean and no dust in the holes.
Technical parameters
| Machine weight | 1450kg | |
| Overall dimension | 1100+ × 1200 × (1950+150) mm | |
| Motor power | 3.37kw + 3kw (Dust Collector) | |
| Power supply | 3 phase, AC 380V, 50Hz | |
| Max. Output | 120000 capsules/h | 150000 capsules/h |
| Capsule size | 00#～5# and safety capsule A～E | |
| Capsule using rate | ≥ 99.5% | |
| Noise index | ≤ 75dBA | |
| Dosage difference | ≤ ±3% (under more than 300mg dosing and 40~80 mesh after granulation) | |
| compressed air | air consumption 0.06m3/min pressure 0.3Mpa | |
| Water supply | Water cycle pump compound water tank, or meet water source | |
| Vacuum degree | -0.02～-0.06 MPa | |
| Water volume | 250L/hour | |
| Enter pipe inner-diameter | 20mm | |
| Waterspout inner-diameter | 27mm | |
| Working temperature | 21℃ ± 3℃ | |
| Working relative humidity | 40～55% | |
| Exhaust capacity | 300m3/h | |
| Special function | Granule and powder mixed filing; Powder collector | |
| Control system | Stepless frequency conversion control, PLC control, with touch screen | |
| Material | Spare part contact with medicine adopt superior S.S 304 & GMP compliable material | |
| Criterion | Comply to GMP completely | |
Service 3: We will dispatch engineers to your site for machine installation and commissioning, and also do the training for your technicians.
Service 4: We makes guarantee of the machine for 12 (twelve) months. During this Warranty period, the seller will provide free spare parts that cause by the machine’s quality within 10 days by fast courier upon receipt of buyer’s notice.(we will also provide one set of spare parts /wear &tear parts to customer along with the shipment of the machine.
Service 5: We warmly welcome the suggestions from customer to make us grow better and produce better machine along with providing better service to customer, and create more value for customer.
Service 6: Before placing the order or before shipping, welcome to our factory to take a visit to inspect our machine. we will pick you up in the airport or train station and arrange your following schedule in our city to bring you a nice journey during this visit.
ABOUT US
Hunan Grand Packing Machinery Co.,Ltd is specialized in the pharmaceutical and packing machinery for more than 10 years, such as plastic ampoule forming filling and sealing machine, capsule filling machine, blister packing machine, strip packaging machine, cartoning machine etc. We have provided services and machines to many different countries and regions in the whole world, such as Indonesia, Thailand, Malaysia, Philippines, New Zealand, Korea,the Middle East area, Poland, Belgium, France, UK, Greece, Italy, Turkey, USA, central and south America such as Trinidad and Tobago,Mexico, Brazil, Russia, Ukraine, UZ, Tunisia, Algeria, Morroco etc. And we always gain the good reputation from customer both from the machine quality and after sales service.
customer visit at our factory and our visit to customer
Our factory
We are cooperating with various kinds of factories and companies in different fields, including pharmaceutical factory, food factory, supplement factory, agrochemical factory such as for pesticide, fertilizer, personal care product factory, such as for cosmetic product, daily use product, stationery factory, hardware factory etc.
