Automatic PVC/PET Plastic Blister Thermoforming Paper Card Sealing Packing Machine

AC-400 is suitable for blister paper card package( half face sealing ), such as daily commodity ( razor, rubber,nipple,sticky hook),small hardware (battery, electronics, glue), stationery (pencil, eraser, correction fluid, solid glue) and so on.
Availability:
Quantity:
  • GAC-400

  • GRAND PACKING

  • 8422303090


AC400

GAC-400 is suitable for blister paper card package( half face sealing ), such as daily commodity ( razor, rubber,nipple,sticky hook),small hardware (battery, electronics, glue), stationery (pencil, eraser, correction fluid, solid glue) and so on.


Working Principle

The production process is  PVC heating---Blister card forming---servo motor traction---blister card cutting---scrap collection---blister card grab to the rotary plate by manipulator--manual place the product--- paper card lay down ----blister and paper card sealing----product output

(Optional device: euro-hole machine, labelling machine,ink-jet printer)


Machine Detail

*six truntable station
*from blister forming to paper -blister heat sealing
*Cam driven ,stable running
*can design feeder according to your product shape




Main Technical Parameter


Mode
AC-380
AC-400
AC-330
AC-600
AC-800
AC-400H
Production speed
15-20 cycles/min
15-20 cycles/min
8-14 cycles/min
15-18 cycles/min
10-15 cycles/min
15-20 cycles/min
Stroke range
30-200mm
30-220mm
30-300mm
30-260mm
30-200mm
30-200mm
Max forming area(mm)
370x170/370x200
370x170/370x230
315*250
550x170/550x230
180*400
180*350
Max standard forming depth
38/50mm
38/50mm
25/40mm
38/50mm
38/50mm
38/50mm
Forming heating power
3.5kw(*2)
3.5kw(*2)
3kw(*2)
3.5kw(*2)
3.5kw(*2)
3.5kw(*2)
Heat sealing power
4.5kw
4.5kw
3.5kw
4.5kw
3kw
/
Total power
13.5kw
13.5kw
13kw
13kw
12kw
15kw
Air consumption
consumption ≥0.5 m⊃3;/min
Air Pressure
0.5-0.8mpa
Packing material
(PVC/PET)
thickness0.15-0.5mm
Max paper dimension
170x400/220x350
400x250/170x500
320x255
600x250/600x300
220x450
200x400
Total Weight
2500kg
2500kg
3500kg
2500kg
1800kg
2500kg
Machine dimension(L*W*H)
4600*1550*1850mm
4600*1550*1850mm
6200*800*1880mm
6200*800*1880mm
2870*1950*1900mm
5100*4190*1880mm

机器汇总



Sample Display

样品行业

样品

Production Process

工位

Company Information

                                                                           ABOUT US

 company

Hunan Grand Packing Machinery Co.,Ltd is specialized in the pharmaceutical and packing machinery for more than 10 years, such as plastic ampoule forming filling and sealing machine, capsule filling machine, blister packing machine, strip packaging machine, cartoning machine etc. We have provided services and machines to many different countries and regions in the whole world, such as Indonesia, Thailand, Malaysia, Philippines, New Zealand, Korea,the Middle East area, Poland, Belgium, France, UK, Greece, Italy, Turkey, USA, central and south America such as Trinidad and Tobago,Mexico, Brazil, Russia, Ukraine, UZ, Tunisia, Algeria, Morroco etc. And we always gain the good reputation from customer both from the machine quality and after sales service.


about 260_blister packing machine

Our Service

1.We will dispatch engineers to your site for machine installation and commissioning, and also do the training for your technicians.

2.We makes guarantee of the machine for 12 (twelve) months. During this Warranty period, the seller will provide free spare parts that cause by the machine’s quality within 10 days by fast courier upon receipt of buyer’s notice.(we will also provide one set of spare parts /wear &tear parts to customer along with the shipment of the machine.
3.We warmly welcome the suggestions from customer to make us grow better and produce better machine along with providing better service to customer, and create more value for customer.
4.Before placing the order or before shipping, welcome to our factory to take a visit to inspect our machine. we will pick you up in the airport or train station and arrange your following schedule in our city to bring you a nice journey during this visit.
